Pristine condition never used open box.  Professionally tested to ensure 100% functionality.  Bios updated to latest.

Learn more about ASRock B550M Pro SE

Model

Brand

ASRock

Model

B550M Pro SE

Supported CPU

CPU Socket Type

AM4

CPU Type

– Supports AMD AM4 Socket Ryzen 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors*
* Not compatible with AMD Athlon™ Processors.

Chipsets

Chipset

AMD PRO 565

Memory

Number of Memory Slots

4x288pin (DDR4)

Memory Standard

– AMD Ryzen series CPUs (Vermeer) support DDR4 4533+(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
– AMD Ryzen series CPUs (Matisse) support DDR4 4533+(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
– AMD Ryzen series APUs (Cezanne) support DDR4 4733+(OC)/4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
– AMD Ryzen series APUs (Renoir) support DDR4 4733+(OC)/4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memory*
– AMD Ryzen series APUs (Picasso) support DDR4 3333+(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buffered memory*
* For Ryzen Series APUs (Picasso, Cezanne and Renoir), ECC is only supported with PRO CPUs.
* Please refer to Memory Support List on ASRock’s website for more information. (https://www.asrock.com/)
* For non-XMP memory frequency support, please refer to the Specification on ASRock’s website.
* For more details, please refer to the QVL on ASRock’s website.

Maximum Memory Supported

128GB

Memory Feature

Supports Extreme Memory Profile (XMP) memory modules

Expansion Slots

PCI Express 4.0 x16

AMD Ryzen series CPUs (Vermeer and Matisse)
– 2 x PCIe x16 Slots (PCIE1: Gen4x16 mode; PCIE3: Gen3 x4 mode)*
AMD Ryzen series APUs (Cezanne and Renoir)
– 2 x PCIe x16 Slots (PCIE1: Gen3x16 mode; PCIE3: Gen3 x4 mode)*
AMD Ryzen series APUs (Picasso)
– 2 x PCIe x16 Slots (PCIE1: Gen3x8 mode; PCIE3: Gen3 x4 mode)*
* Supports NVMe SSD as boot disks
– Supports AMD CrossFire

PCI Express x1

1 x PCIe 3.0 x1 Slot (PCIE2: x1 mode)

Storage Devices

SATA 6Gb/s

4 x SATA 6Gb/s

M.2

CPU:
– 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode (with Vermeer, Matisse) or Gen3x4 (32 Gb/s) mode (with Cezanne, Renoir and Picasso)*
Chipset:
– 1 x M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes*

* Supports NVMe SSD as boot disks

SATA RAID

0/1/10

Onboard Audio

Audio Chipset

7.1 CH HD Audio (Realtek ALC897 Audio Codec)

Audio Channels

7.1 Channels

Onboard LAN

LAN Chipset

Dragon RTL8125BG
– Supports Dragon 2.5G LAN Software
– Smart Auto Adjust Bandwidth Control
– Visual User Friendly UI
– Visual Network Usage Statistics
– Optimized Default Setting for Game, Browser, and Streaming Modes
– User Customized Priority Control

Max LAN Speed

2.5Gbps

Rear Panel Ports

Back I/O Ports

– 1 x PS/2 Mouse/Keyboard Port
– 1 x HDMI Port
– 1 x DisplayPort 1.4
– 4 x USB 3.2 Gen1 Ports
– 2 x USB 2.0 Ports
– 1 x RJ-45 LAN Port with LED
– HD Audio Jacks: Line in / Front Speaker / Microphone

Internal I/O Connectors

Onboard USB

– 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
– 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

Other Connectors

– 1 x SPI TPM Header
– 1 x Power LED and Speaker Header
– 2 x RGB LED Headers*
– 2 x Addressable LED Headers**
– 1 x CPU Fan Connector (4-pin)***
– 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****
– 1 x Front Panel Audio Connector

* Support in total up to 12V/3A, 36W LED Strip
** Support in total up to 5V/3A, 15W LED Strip
*** CPU_FAN1 supports the fan power up to 1A (12W).
**** CHA_FAN1~3/WP support the fan power up to 2A (24W).
**** CHA_FAN1~3/WP can auto detect if 3-pin or 4-pin fan is in use.

Physical Spec

Form Factor

Micro ATX

Dimensions (W x L)

9.6″ x 9.6″

Power Pin

– 1 x 24 pin ATX Power Connector
– 1 x 8 pin 12V Power Connector

Windows 11 Compatibility

Windows 11

Supported

Features

Features

Rock-Solid Durability
– 8 Power Phase
– Pre-Installed I/O Shield
Ultrafast Connectivity
– 2.5G LAN
Software
– ASRock Motherboard Utility (A-Tuning)
– ASRock Dragon 2.5G LAN Software
– ASRock Polychrome SYNC
* These utilities can be downloaded from ASRock Live Update & APP Shop.
UEFI
– ASRock Full HD UEFI
– ASRock Instant Flash
