Pristine condition never used open box.  Professionally tested to ensure 100% functionality.  Bios updated to latest.

Learn more about ASUS TUF GAMING Z890-PLUS WIFI

Model

Brand

ASUS

Model

TUF GAMING Z890-PLUS WIFI

Supported CPU

CPU Socket Type

LGA 1851

CPU Type

Intel Core Ultra Processors (Series 2)

Chipsets

Chipset

Intel Z890

Memory

Number of Memory Slots

4x288pin (DDR5)

Memory Standard

DDR5 4400 / DDR5 4800 / DDR5 5000 / DDR5 5200 / DDR5 5400 / DDR5 5600 / DDR5 5800 / DDR5 6000 / DDR5 6200 / DDR5 6400 / DDR5 6600 / DDR5 6800 / DDR5 7000 / DDR5 7200 / DDR5 7400 / DDR5 7600 / DDR5 7800 / DDR5 7900 / DDR5 7950 / DDR5 8000 / DDR5 8200 / DDR5 8266 / DDR5 8400 / DDR5 8600 / DDR5 8666 / DDR5 8800 / DDR5 8933 / DDR5 9000 / DDR5 9066

Maximum Memory Supported

192GB

Channel Supported

Dual Channel

Memory Feature

Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel Extreme Memory Profile (XMP) memory module
ASUS Enhanced Memory Profile III(AEMPIII)
** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Expansion Slots

PCI Express 5.0 x16

1 x PCI Express 5.0 x16

PCI Express 4.0 x16

1 x PCI Express 4.0 x16

Storage Devices

SATA 6Gb/s

4 x SATA 6Gb/s

M.2

1 x M.2 (Support PCIe 5.0 x4) / 3 x M.2 (Support PCIe 4.0 x4)

Onboard Audio

Audio Channels

7.1 Channels

Onboard LAN

Max LAN Speed

2.5Gbps

Wireless LAN

Wi-Fi 802.11 be

Rear Panel Ports

Back I/O Ports

1 x DisplayPort / 1 x Flash BIOS Button / 1 x HDMI / 1 x Optical S/PDIF Out / 1 x Thunderbolt 4 / 1 x USB 3.1 Gen 2 Type-C / 5 x Audio Jacks / 6 x USB 3.1 Gen 2 Type-A

Software Feature

Windows 11

Supported

Physical Spec

Form Factor

ATX
