Pristine condition never used open box.  Professionally tested to ensure 100% functionality.  Bios updated to latest.

Learn more about GIGABYTE A520I AC

Model

Brand

GIGABYTE

Model

A520I AC

Supported CPU

CPU Socket Type

AM4

CPU Type

AMD Socket AM4, support for: AMD Ryzen 5000 Series / 3rd Gen Ryzen and 3rd Gen Ryzen with Radeon Graphics Processors* Support for Ryzen 5000 Series with BIOS UPDATE. Refer to GIGABYTE website for CPU support list.

Chipsets

Chipset

AMD A520

Memory

Number of Memory Slots

2×288pin

Memory Standard

3rd Gen AMD Ryzen Processors:Support for DDR4 5100(O.C.)/ 4866(O.C.)/ 4600(O.C.)/ 4400(O.C.)/ 4000(O.C.)/ 3600(O.C.)/ 3333(O.C.)/ 3200/ 2933/ 2667/ 2400/ 2133 MHz memory modules3rd Gen AMD Ryzen with Radeon Graphics processors:Support for DDR4 5300(O.C.)/ 5200(O.C.)/ 5000(O.C.)/ 4866(O.C.)/ 4600(O.C.)/ 4400(O.C.)/ 4000(O.C.)/ 3600(O.C.)/ 3333(O.C.)/ 3200/ 2933/ 2667/ 2400/ 2133 MHz memory modules

Maximum Memory Supported

64GB

Channel Supported

Dual Channel

Expansion Slots

PCI Express 3.0 x16

1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16

Storage Devices

SATA 6Gb/s

4 x SATA 6Gb/s

M.2

1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)

SATA RAID

0/1/10

Onboard Video

Onboard Video Chipset

Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors:1 x DisplayPort port, supporting a maximum resolution of 5120×2880@60 Hz* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.2 x HDMI ports, supporting a maximum resolution of 4096×2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.Support for up to 3 displays at the same timeMaximum shared memory of 16GB

Onboard Audio

Audio Chipset

Realtek ALC887

Audio Channels

2/4/5.1/7.1-channel* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software.

Onboard LAN

LAN Chipset

Realtek GbE LAN chip

Max LAN Speed

10/100/1000Mbps

Wireless LAN

Intel Wi-Fi AC 3168WIFI 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-BandSupport for 11ac wireless standard and up to 433 Mbps data rate* Actual data rate may vary depending on environment and equipment.

Bluetooth

BLUETOOTH 4.2

Rear Panel Ports

Back I/O Ports

1 x DisplayPort2 x HDMI ports4 x USB 3.2 Gen 1 ports2 x USB 2.0/1.1 ports1 x Q-Flash Plus button1 x RJ-45 ports2 x SMA antenna connectors (1T1R)3 x audio jacks

Internal I/O Connectors

Onboard USB

1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header

Other Connectors

1 x CPU fan header2 x system fan headers1 x addressable LED strip header1 x RGB LED strip header1 x front panel header1 x front panel audio header1 x speaker header1 x Trusted Platform Module (TPM) header (2×6-pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper

Physical Spec

Form Factor

Mini ITX

LED Lighting

RGB

Dimensions (W x L)

6.7″ x 6.7″

Power Pin

1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector

Features

Features

I/O Controller:iTE I/O Controller ChipH/W Monitoring:Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the cooler you install.BIOS:1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique Features:Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.@BIOSEasyTuneFast BootGame BoostON/OFF ChargeRGB FusionSmart BackupSystem Information ViewerSupport for Q-Flash PlusSupport for Q-FlashSupport for Xpress InstallBundled Software:Norton Internet Security (OEM version)Realtek 8118 Gaming LAN Bandwidth Control UtilityOperating System:Support for Windows 10 64-bit
